Keysight E9300A/100 Average Power Sensor
Request a quote
Keysight E9300A/100 RF power sensor with Type N (male) connector, 80 dB dynamic range (-60 to +20 dBm), and 10 MHz to 18 GHz coverage.
Product details
| Model | E9300A/100 |
| Manufacturer | Keysight |
| Category | RF Power Sensors |
| Availability | Made to order |
Description
Overview
The Keysight E9300A/100 is a diode power sensor configured with a standard Type N (male) connector for measuring average RF power across all modulation formats. Offering an 80 dB dynamic range from -60 to +20 dBm and frequency coverage of 10 MHz to 18 GHz, it integrates with Keysight's EPM, EPM-P, and P-series power meters. The sensor's calibration factors, linearity, and temperature compensation data are stored in EEPROM.
Key Features
- Type N (male) connector for standard RF connections
- Frequency range: 10 MHz to 18 GHz
- Dynamic range: -60 dBm to +20 dBm (80 dB total)
- Measures average power of all modulation formats (WCDMA, CDMA, TDMA, OFDM)
- High maximum power specification
- Low SWR for reducing mismatch uncertainty
- Calibration and temperature compensation stored in EEPROM
- Fast measurement capability: up to 400 readings per second with compatible power meters
Applications
- RF and microwave power measurement with standard Type N connections
- Validation and characterization of digital modulation signals
- Power amplifier and transmitter performance testing
Specifications
