Bird 7027-1-594301-1212 Semiconductor Pulse Sensor
Request a quote
Bird 7027-1-594301-1212 is a compact semiconductor pulse sensor with 1% accuracy and NIST calibration, measuring 10 W to 10 kW RF power at 13.56 MHz via USB.
Product details
| Model | 7027-1-594301-1212 |
| Manufacturer | Bird |
| Category | RF Power Sensors |
| Availability | Made to order |
Description
Overview
The Bird 7027-1-594301-1212 is a compact semiconductor pulse sensor for RF power measurement at 13.56 MHz. Designed for laboratory and production applications, this 7027 Series sensor covers 10 W to 10 kW with 1% measurement accuracy and NIST traceable calibration. USB connectivity simplifies integration and data acquisition.
Key Features
- Time domain display with gated power measurements (up to four sets of gates)
- NIST traceable calibration with 1% accuracy
- Pulse width measurements down to 1 µs
- Pulse repetition rate measurements from 10 Hz to 100 kHz
- Harmonic filtering and external sync input
- USB connectivity for simple computer integration
- SCPI command set for test automation
- Dual HN(f) connectors for flexible configuration
- Optional RF Interlock protection
Applications
- Semiconductor processing at 13.56 MHz frequency
- RF source characterization and optimization
- Pulse power measurement in laboratory settings
- Portable power measurement and data logging
Specifications
| Connector Type | HN (f) |
| Series | 7027 Series |
| Impedance | 50 Ohms |
