Tektronix RSA503A/04 Real-Time Spectrum Analyzer
Tektronix RSA503A/04 is a USB-based real-time spectrum analyzer with 9 kHz to 3 GHz frequency range, 40 MHz bandwidth, and integrated tracking generator.
Product details
| Model | RSA503A/04 |
| Manufacturer | Tektronix |
| Category | Benchtop Spectrum Analyzers |
| Availability | Made to order |
Description
Overview
The Tektronix RSA503A/04 is a USB-based real-time spectrum analyzer combining high-performance swept spectrum analysis with 40 MHz real-time bandwidth for transient capture and vector analysis. Built for spectrum managers, interference hunters, and network maintenance personnel, it captures signals with exceptional fidelity in harsh environments and enables both traditional spectrum analysis and gain/loss measurements for network component testing through its integrated tracking generator.
The lightweight USB form factor moves the weight of instrumentation from the operator to a portable Windows PC or tablet, enabling faster field operations and extended mission duration. With 70 dB dynamic range and wide frequency coverage, signals of interest can be examined with high confidence.
Key Features
- Frequency range: 9 kHz to 3 GHz
- Real-time acquisition bandwidth: 40 MHz
- High-speed full-span sweeps at 70 GHz/sec for rapid discovery
- Integrated tracking generator for gain/loss and antenna measurements
- 15 µsec minimum signal duration with 100% probability of intercept
- Standard GPS/GLONASS/Beidou receiver for mapping and oscillator accuracy
- MIL-STD 28800 Class 2 environmental specifications for harsh conditions
- USB 3.0 interface with SignalVu-PC software for real-time DPX spectrum/spectrogram
- DataVu-PC analysis software for advanced post-processing of recorded signals
- EMC/EMI compliance testing with CISPR detectors and limit line capabilities
- Application programming interface included for custom program development
- Three-year warranty
Applications
- Spectrum management and monitoring
- Interference hunting and identification
- Radio network installation and maintenance
- Transmitter maintenance and testing
- EMC/EMI pre-compliance testing and troubleshooting
- RF network repair and characterization
Included Accessories
- USB 3.0 cable (2 m, A-A connection with screw lock)
- Shoulder strap
- Carrying case with compartments for unit, tablet, and accessories
- WFM200BA Li-Ion rechargeable battery pack
- AC power adapter with power cord
- Connector covers
- Quick-start manual
- API and documentation files
Specifications
| Frequency Range | 0.5 - 4.0 GHz |
| Maximum Frequency | 3 GHz |
| Tracking Generator | Yes |
| Noise Floor | -156 dBm |
| Product Type | USB |
| Preamplifier | Yes |
| Series | RSA500 Series |
| Battery Life | 4 hrs. |
| Battery Type | Li-Ion, Smart Battery compatible with SMBus interface. |
| Includes | USB 3.0 cable (2 M), A-A connection, screw lock, shoulder strap, carrying case (with room for unit, tablet, accessories), quick-start manual (printed), connector covers, WFM200BA Li-Ion rechargeable battery pack, WFM200BA Li-Ion battery pack instructions |
| Input Connector | BNC female, N type female |
| Memory | 8 GB |
| Minimum Frequency | 9 kHz |
| Warranty | 3 Years |
