Rohde & Schwarz FSW85 Signal and Spectrum Analyzer
Request a quote
Rohde & Schwarz FSW85 signal and spectrum analyzer covering 2 Hz to 85 GHz with up to 8.3 GHz analysis bandwidth for 5G, radar, and satellite applications.
Product details
| Model | FSW85 (1331.5003.85) |
| Manufacturer | Rohde & Schwarz |
| Category | Spectrum Analyzers |
| Availability | Made to order |
Description
Overview
The Rohde & Schwarz FSW85 is a high-performance signal and spectrum analyzer covering frequencies from 2 Hz to 85 GHz. Designed for demanding RF and microwave measurements, the FSW85 offers exceptional phase noise performance, wide analysis bandwidth up to 8.3 GHz, and advanced measurement capabilities for 5G, automotive radar, and satellite applications.
Key Features
- Frequency range: 2 Hz to 85 GHz (extendable to 90 GHz with FSW-B90G option)
- Wide analysis bandwidth: up to 8.3 GHz
- Real-time spectrum analysis bandwidth: up to 800 MHz
- Low phase noise: –140 dBc (1 Hz) at 1 GHz carrier, 10 kHz offset (typical)
- 12.1" multitouch display with gesture support
- Parallel measurement applications
- SCPI recorder for automation
- Windows 10 interface design
Applications
- 5G New Radio signal analysis and validation
- Automotive radar (FMCW) characterization
- Satellite RF testing and demodulation
- Pulsed and frequency-hopping radar analysis
- High-frequency component characterization
- Vector signal analysis up to 85 GHz
Specifications
| High Frequency (range) | 50GHz <= 85GHz |
| Low Frequency (range) | DC <= 1kHz |
| Form Factor | Benchtop |
