Rohde & Schwarz FSW50 Signal and Spectrum Analyzer

Overview

The Rohde & Schwarz FSW50 is a high-performance signal and spectrum analyzer designed for advanced RF and microwave measurements up to 50 GHz. With exceptional phase noise performance and wide internal analysis bandwidth of up to 8.3 GHz, it supports characterization of wideband RF components and complex modulated signals used in 5G, radar, satellite, and automotive applications. The 12.1-inch multitouch display provides intuitive operation with support for parallel measurements and real-time analysis.

Key Features

• Frequency range: 2 Hz to 50 GHz
• Maximum analysis bandwidth: 8.3 GHz
• Phase noise: –136 dBc (1 Hz) at 1 GHz, 10 kHz offset
• Displayed Average Noise Level (DANL): –156 dBm (1 Hz) at 2 GHz
• 12.1-inch multitouch touchscreen with gesture support and Windows 10 interface
• Real-time analysis up to 800 MHz bandwidth
• Resolution bandwidths from 1 Hz to 80 MHz
• Multiple measurement applications with parallel display capability
• SCPI recorder for automatic measurement scripting
• Scalable demodulation bandwidth up to 8.3 GHz with optional modules
• Harmonic mixer compatibility for frequencies beyond 50 GHz

Applications

• RF and microwave component testing
• 5G New Radio signal analysis and validation
• Satellite RF signal analysis and demodulation
• Radar and automotive radar signal characterization
• Frequency hopping and transient signal detection
• Vector signal and modulation quality assessment
