Rohde & Schwarz FSW26 Signal and Spectrum Analyzer
Request a quote
Rohde & Schwarz FSW26 offers 2 Hz to 26.5 GHz frequency coverage with 2 GHz analysis bandwidth, –136 dBc phase noise, and multitouch display for RF and microwave measurement applications.
Product details
| Model | FSW26 (1331.5003.26) |
| Manufacturer | Rohde & Schwarz |
| Category | Spectrum Analyzers |
| Availability | Made to order |
Description
Overview
The Rohde & Schwarz FSW26 is a high-performance signal and spectrum analyzer designed for demanding RF and microwave measurements up to 26.5 GHz. With exceptional phase noise performance and wide analysis bandwidth, it supports characterization of wideband RF components, communications systems, and radar applications. The 12.1-inch multitouch display and Windows 10 interface provide intuitive operation with support for parallel measurements.
Key Features
- Frequency range: 2 Hz to 26.5 GHz
- Maximum analysis bandwidth: 2 GHz
- Phase noise: –136 dBc (1 Hz) at 1 GHz, 10 kHz offset
- Displayed Average Noise Level (DANL): –156 dBm (1 Hz) at 2 GHz
- 12.1-inch multitouch touchscreen with gesture support and Windows 10 interface
- Real-time analysis up to 160 MHz bandwidth
- Resolution bandwidths from 1 Hz to 80 MHz
- Multiple measurement applications with parallel display capability
- SCPI recorder for automatic measurement scripting
- Preamplifier option available for improved noise floor to –169 dBm (1 Hz)
Applications
- RF component and system characterization
- 5G New Radio signal analysis
- Radar and automotive radar testing
- Microwave transmission system measurements
- Vector signal and modulation analysis
- Frequency hopping and transient signal detection
Specifications
| High Frequency (range) | 20GHz <= 50GHz |
| Low Frequency (range) | DC <= 1kHz |
| Form Factor | Benchtop |
