Rohde & Schwarz FSVA13 Signal and Spectrum Analyzer
Request a quote
Rohde & Schwarz FSVA13 signal and spectrum analyzer with frequency coverage to 13.6 GHz and exceptional phase noise performance for demanding RF measurements.
Product details
| Model | FSVA13 (1321.3008.14) |
| Manufacturer | Rohde & Schwarz |
| Category | Spectrum Analyzers |
| Availability | Made to order |
Description
Overview
The Rohde & Schwarz FSVA13 is a versatile signal and spectrum analyzer designed for RF system development, production, installation, and service. The instrument combines high dynamic range with exceptionally low phase noise, making it ideal for demanding spectral measurements such as adjacent channel leakage ratio (ACLR) and phase noise characterization.
Key Features
- Frequency range: 10 Hz to 13.6 GHz with optional extension to 500 GHz using harmonic mixers
- Signal analysis bandwidth up to 160 MHz with optional FSV-B160 module
- Intuitive touchscreen-based user interface for convenient operation
- Level measurement uncertainty of 0.4 dB up to 7 GHz
- Low displayed average noise level (DANL): typically –151 dBm (1 Hz) at 13 GHz
- High third-order intercept (TOI): typically 20 dBm for frequencies below 3.6 GHz
- Very low phase noise: typically –118 dBc (1 Hz) at 1 GHz, 10 kHz offset
- Removable solid state or hard disk drives for data confidentiality
Applications
- Phase noise and noise figure measurements
- Vector signal analysis and analog demodulation
- EMI diagnostics and RFI detection
- ACLR measurements on narrowband signals
- Wireless standards testing: LTE, WLAN (802.11ac), WCDMA, GSM, Bluetooth
- RF component and module characterization
Specifications
| High Frequency (range) | 10GHz <= 20GHz |
| Low Frequency (range) | DC <= 1kHz |
| Form Factor | Benchtop |
