Rohde & Schwarz FSU50 Spectrum Analyzer
Request a quote
Rohde & Schwarz FSU50 provides frequency coverage to 50 GHz with 0.3 dB measurement uncertainty, low phase noise at –133 dBc, and superior performance for advanced RF testing.
Product details
| Model | FSU50 (1166.1660.50) |
| Manufacturer | Rohde & Schwarz |
| Category | Spectrum Analyzers |
| Availability | Made to order |
Description
Overview
The Rohde & Schwarz FSU50 is a high-performance spectrum analyzer engineered for RF and microwave analysis up to 50 GHz. Featuring exceptional phase noise, comprehensive measurement functions, and wide dynamic range, it excels in advanced development and testing for aerospace, defense, and telecommunications applications requiring precision measurements at the highest frequencies.
Key Features
- Frequency range: 20 Hz to 50 GHz
- Phase noise: typ. –133 dBc (1 Hz) at 640 MHz
- Displayed average noise level: typ. –156 dBm at 1 GHz, typ. –131 dBm at 50 GHz
- Total measurement error: 0.3 dB (f < 3.6 GHz)
- Resolution bandwidth: 10 Hz to 50 MHz with FFT options
- TOI: > 20 dBm, typical +25 dBm
- 1 dB compression: +13 dBm
- ACLR (3GPP): typ. 77–84 dB
- Full range of trace detectors and analysis functions
- Fast sweep: 2.5 ms at span ≥ 10 Hz
Applications
- 5G and advanced wireless testing
- Millimeter-wave signal analysis
- Base station component characterization
- Aerospace and defense RF testing
- RADAR and high-frequency measurements
Included Accessories
- Power cable
- Printed quick start guide
- CD-ROM with operating and service manuals
- Test port adapters with 2.4 mm and N female connectors
Specifications
| High Frequency (range) | 20GHz <= 50GHz |
| Low Frequency (range) | DC <= 1kHz |
