Rohde & Schwarz FSU46 Spectrum Analyzer
Request a quote
Rohde & Schwarz FSU46 spectrum analyzer covers 20 Hz to 46 GHz with 0.3 dB measurement uncertainty and exceptional phase noise performance for high-frequency RF and microwave testing.
Product details
| Model | FSU46 (1166.1660.46) |
| Manufacturer | Rohde & Schwarz |
| Category | Spectrum Analyzers |
| Availability | Made to order |
Description
Overview
The Rohde & Schwarz FSU46 is a high-frequency spectrum analyzer designed for RF and microwave analysis up to 46 GHz. With outstanding phase noise characteristics, wide dynamic range, and comprehensive measurement capabilities, it is ideally suited for base station testing, aerospace applications, and high-frequency signal analysis in demanding measurement environments.
Key Features
- Frequency range: 20 Hz to 46 GHz
- Phase noise: typ. –133 dBc (1 Hz) at 640 MHz
- Displayed average noise level: typ. –156 dBm at 1 GHz, typ. –143 dBm at 40 GHz
- Total measurement error: 0.3 dB (f < 3.6 GHz)
- Resolution bandwidth: 10 Hz to 50 MHz
- TOI: > 20 dBm, typical +25 dBm
- 1 dB compression: +13 dBm
- ACLR (3GPP): typ. 77–84 dB
- Multiple trace detectors for signal analysis
- Sweep time: 2.5 ms to 16,000 s at span ≥ 10 Hz
Applications
- Base station and component testing
- RADAR and advanced signal analysis
- High-frequency RF measurements
- Aerospace and defense applications
- 3GPP and modulation characterization
Included Accessories
- Power cable
- Printed quick start guide
- CD-ROM with manuals
- Test port adapters with 2.92 mm K female and N female connectors
Specifications
| High Frequency (range) | 20GHz <= 50GHz |
| Low Frequency (range) | DC <= 1kHz |
