Rohde & Schwarz FSU26 Spectrum Analyzer
Request a quote
Rohde & Schwarz FSU26 delivers frequency coverage to 26.5 GHz with 0.3 dB measurement uncertainty, low phase noise at –133 dBc, and versatile analysis functions for RF and microwave testing.
Product details
| Model | FSU26 (1313.9000.26) |
| Manufacturer | Rohde & Schwarz |
| Category | Spectrum Analyzers |
| Availability | Made to order |
Description
Overview
The Rohde & Schwarz FSU26 is a high-performance spectrum analyzer for RF and microwave analysis up to 26.5 GHz. Featuring exceptional phase noise, wide dynamic range, and comprehensive measurement capabilities, it is ideal for base station development, radar signal detection, and spurious emission testing in aerospace and defense applications.
Key Features
- Frequency range: 20 Hz to 26.5 GHz
- Phase noise: typ. –133 dBc (1 Hz) at 640 MHz
- Displayed average noise level: typ. –156 dBm at 1 GHz, typ. –153 dBm at 13 GHz
- Total measurement error: 0.3 dB (f < 3.6 GHz)
- Resolution bandwidth: 10 Hz to 50 MHz with FFT filtering
- TOI: > 20 dBm, typical +25 dBm
- 1 dB compression: +13 dBm
- ACLR (3GPP): typ. 77–84 dB with noise correction
- Versatile trace detectors including Peak, RMS, Average, and CISPR modes
- Fast sweep speeds: 2.5 ms minimum at span ≥ 10 Hz
Applications
- Base station development and testing
- RADAR development and spurious emission detection
- 3GPP and modulation analysis
- RF signal characterization
- Aerospace and defense measurements
Included Accessories
- Power cable
- Printed quick start guide
- CD-ROM with operating and service manuals
- Test port adapters with 3.5 mm and N female connectors
Specifications
| High Frequency (range) | 20GHz <= 50GHz |
| Low Frequency (range) | DC <= 1kHz |
