Rohde & Schwarz FSQ8 RF Signal and Spectrum Analyzer
Request a quote
Rohde & Schwarz FSQ8 is a spectrum and signal analyzer covering 20 Hz to 8 GHz with 28 MHz analysis bandwidth, +25 dBm TOI, and noise floor of –173 dBm with preamplifier.
Product details
| Model | FSQ8 (1155.5001.08) |
| Manufacturer | Rohde & Schwarz |
| Category | Spectrum Analyzers |
| Availability | Made to order |
Description
Overview
The Rohde & Schwarz FSQ8 is a high-performance spectrum analyzer and wideband signal analyzer that combines outstanding spectrum analysis features with advanced signal analysis capabilities. With its large analysis bandwidth and exceptional RF characteristics, it is ideal for measuring complex broadband signals and performing detailed modulation analysis.
Key Features
- Frequency range: 20 Hz to 8 GHz
- 28 MHz signal analysis bandwidth, optionally 120 MHz
- Outstanding RF characteristics: TOI typ. +25 dBm, 1 dB compression point +13 dBm
- Very low noise: –173 dBm (1 Hz) DANL with noise correction and preamplifier
- 84 dBc ACLR/3GPP with noise correction
- 16 Msample I/Q memory, expandable up to 705 Msample
- Analog and digital baseband signal analysis with FSQ-B71/B17 options
- Multiple firmware applications for extended signal analysis
Applications
- WLAN and IEEE 802.11n/ac broadband signal measurement
- 3GPP LTE and WCDMA multicarrier signal analysis
- Modulation accuracy and code domain power measurement
- Development and production RF testing
Specifications
| Frequency Range | 20 Hz to 8 GHz |
| Signal Analysis Bandwidth | 28 MHz, optionally 120 MHz |
| Third Order Intercept (TOI) | +25 dBm typical |
| 1 dB Compression Point | +13 dBm |
| ACLR/3GPP | 84 dBc with noise correction |
| Displayed Average Noise Level (DANL) | –173 dBm (1 Hz) with noise correction and preamplifier |
| I/Q Memory | 16 Msample, expandable to 705 Msample |
| Analysis Modes | Analog and digital baseband |
