Rohde & Schwarz FSMR26 Measuring Receiver
Request a quote
Rohde & Schwarz FSMR26 is a multi-function measuring receiver combining level calibrator, modulation analyzer, spectrum analyzer, and audio analyzer with 26.5 GHz frequency coverage.
Product details
| Model | FSMR26 (1313.9200.26) |
| Manufacturer | Rohde & Schwarz |
| Category | Spectrum Analyzers |
| Availability | Made to order |
Description
Overview
The Rohde & Schwarz FSMR26 is a compact measuring receiver that consolidates the functionality of multiple test instruments into a single unit. It serves as a precision level calibrator, modulation analyzer, audio analyzer, and full-featured spectrum analyzer. The FSMR26 is engineered for RF signal generator and attenuator calibration with exceptional level linearity and stability, making it ideal for calibration labs, development facilities, and military metrology applications.
Key Features
- Frequency range from 20 Hz to 26.5 GHz
- Highly accurate level calibrator with 0.015 dB + 0.005 dB/10 dB linearity
- Wide measurement range from +30 dBm to -140 dBm
- Modulation analyzer for AM, FM, and PM signals
- Audio analyzer with THD and SINAD measurements
- High-performance spectrum analyzer functionality
- Compatible with R&S NRP power sensors
- Very high level stability over time
- Complete operation control from front panel
- Traceable calibration with documented procedures
Applications
- Signal generator calibration and verification
- Attenuator calibration and testing
- RF and microwave measurements
- Compliance testing and verification
- Military and aerospace RF measurements
Specifications
| High Frequency (range) | 20GHz <= 50GHz |
| Low Frequency (range) | DC <= 1kHz |
