Rohde & Schwarz FPL1044 Spectrum Analyzer
Request a quote
Rohde & Schwarz FPL1044 portable spectrum analyzer extends to 44 GHz with –163 dBm DANL with preamplifier, optional 40 MHz analysis bandwidth, and touchscreen interface.
Product details
| Model | FPL1044 (1304.0004.44) |
| Manufacturer | Rohde & Schwarz |
| Category | Spectrum Analyzers |
| Availability | Made to order |
Description
Overview
The Rohde & Schwarz FPL1044 is an advanced portable spectrum analyzer extending measurement capabilities to 44 GHz, making it ideal for higher-frequency RF applications. Like the rest of the FPL Series, it serves as a comprehensive instrument for spectrum analysis, power measurement, and analog/digital signal analysis. The FPL1044 combines high performance with portability, featuring low phase noise, excellent sensitivity, and a user-friendly touchscreen interface.
Key Features
- Extended frequency range 5 kHz to 44 GHz
- SSB phase noise: typ. –108 dBc (1 Hz) at 10 kHz offset (1 GHz carrier)
- DANL with preamplifier: typ. –163 dBm/Hz from 10 MHz to 2 GHz
- 40 MHz analysis bandwidth (optional)
- 10.1 inch touchscreen with 1280 x 800 pixel resolution and gesture support
- Portable design: 6 kg weight with carrying handle
- Optional internal lithium-ion battery for 3+ hours operation
- Third-order intercept point: +20 dBm
- Low spurious response: –70 dBc up to 10 MHz offset, –80 dBc at higher offsets
Applications
- Millimeter-wave and high-frequency RF measurements
- Research and education institutions
- Aerospace and defense testing
- 5G and satellite communication analysis
- Service and maintenance of broadband systems
- IoT and wireless device development
- Production testing and quality assurance
Included Accessories
- Power cable
- Quick start guide
Specifications
| Frequency Range | 5 kHz to 44 GHz |
| Phase Noise | < –105 dBc (1 Hz) at 10 kHz offset (1 GHz carrier) |
| DANL (with preamplifier) | < –163 dBm/Hz (10 MHz to 2 GHz) |
| Resolution Bandwidth | 1 Hz to 10 MHz |
| Analysis Bandwidth | 10 MHz standard, 40 MHz optional |
| Third-Order Intercept Point | +20 dBm |
| Spurious Response | –70 dBc (up to 10 MHz offset), –80 dBc (higher offsets) |
| Display | 10.1 inch touchscreen, 1280 x 800 pixels |
| Weight | 6 kg |
| Dimensions | Depth 23.5 cm (compact footprint) |
| Battery Life | 3+ hours (optional internal battery) |
| Operating Temperature | 0°C to +50°C |
| Interfaces | USB, LAN, GPIB (optional), RF input BNC |
