RIGOL DSA705 RF Spectrum Analyzer
Request a quote
RIGOL DSA705 is a compact RF spectrum analyzer covering 100 kHz to 500 MHz with built-in preamplifier and 8-inch display for EMI pre-compliance testing.
Product details
| Model | DSA705 |
| Manufacturer | RIGOL |
| Category | Spectrum Analyzers |
| Availability | Made to order |
Description
Overview
The RIGOL DSA705 is a compact RF spectrum analyzer designed for EMI pre-compliance testing and signal analysis. It covers frequencies from 100 kHz to 500 MHz and features a built-in preamplifier for enhanced sensitivity. The analyzer combines the stability of digital spectrum analysis with the rapid capture characteristics of analog designs, making it cost-effective for engineers needing to quickly identify and locate product issues for EMC compliance.
Key Features
- Frequency range: 100 kHz to 500 MHz
- Displayed average noise level (DANL) <-155 dBm/Hz typical with preamplifier on
- Minimum resolution bandwidth (RBW) 100 Hz
- Phase noise <-80 dBc/Hz @10 kHz offset
- Level measurement uncertainty <1.5 dB
- 8-inch (800 x 480) high-definition display
- Linear and logarithmic frequency axis
- Connectivity: LAN (LXI), USB Host & Device, PictBridge support
- Compact size and light weight
Applications
- EMI pre-compliance testing for product design
- 2FSK modulation signal measurement and analysis
- Remote controller and automotive signal analysis
- Quick problem location and product characterization
Specifications
| Frequency Range | 0.5 - 4.0 GHz |
| Maximum Frequency | 500 MHz |
| Noise Floor | -130 dB |
| Product Type | Benchtop |
| Preamplifier | Yes |
| Series | DSA700 Series |
| Display Type | 8" LCD |
| Input Connector | N female, BNC female, USB A/B Plug version 2.0, 10/100Base, RJ-45, IEEE488.2 |
| Interface | LAN / Ethernet, USB Host, USB |
| Minimum Frequency | 100 kHz |
| Resolution | 100 Hz to 1 MHz |
| Warranty | 3 Years |
