Keysight N9937A Spectrum Analyzer
Keysight N9937A 18 GHz handheld spectrum analyzer with 10 MHz analysis bandwidth, lightweight 3.0 kg design, and configurable options.
Product details
| Model | N9937A |
| Manufacturer | Keysight |
| Category | Spectrum Analyzers |
| Availability | Made to order |
Description
Overview
The Keysight N9937A is an 18 GHz handheld spectrum analyzer designed for routine maintenance, in-depth troubleshooting, and field testing applications. This lightweight spectrum analyzer delivers Keysight-quality measurements wherever you need to go, with configurations for spectrum analysis, power measurement, and advanced signal analysis.
The base function provides spectrum analysis with the ability to expand capabilities through optional features including a tracking generator, interference analyzer, built-in power meter, pre-amplifier, GPS receiver, and remote control via mobile devices. Select the options you need and carry a single portable instrument for comprehensive field testing.
Key Features
- Frequency range 5 kHz to 18 GHz with intuitive interface
- Maximum analysis bandwidth 10 MHz with real-time spectrum analysis capability
- Lightweight design at only 3.0 kg (6.6 lb) for field portability
- Accurate spectrum analyzer measurements (±0.5 dB) without requiring instrument warm-up
- Expandable with up to 20 software applications via license-key activation
- Spectrogram display and recording for locating interfering signals
- Power measurements with USB power sensor support
- Optional built-in GPS receiver for location logging
Applications
- Spectrum monitoring and analysis
- Cable and antenna measurements
- Interference detection and location
- Power and pulse measurements
- 5G/LTE field testing and OTA measurements
- Routine maintenance and preventive testing
- Signal strength and field measurements
Specifications
| High Frequency (range) | 10GHz <= 20GHz |
| Low Frequency (range) | 100kHz <= 1MHz |
| Frequency Range | 15.0 - 30.0 GHz |
| Maximum Frequency | 18 GHz |
| Tracking Generator | No |
| Preamplifier | No |
| Noise Floor | -155 dBm |
| Series | N993xA Series |
| Battery Life | 3.5 hrs. |
| Connector Type | N (f) |
| Display | 6.5" LCD Color |
| Includes | Base model includes the cable and antenna analyzer |
| Interface | USB, LAN |
| Minimum Frequency | 100 kHz |
| Number of Ports | 2 |
| Type | Handheld |
| Warranty | 3 Years |
