Keysight N9936A Handheld Microwave Spectrum Analyzer
Request a quote
Keysight N9936A handheld microwave spectrum analyzer, 100 kHz to 14 GHz, expandable with optional tracking generator and power meter capabilities.
Product details
| Model | N9936A |
| Manufacturer | Keysight |
| Category | Spectrum Analyzers |
| Availability | Made to order |
Description
Overview
The Keysight FieldFox N9936A is a lightweight handheld microwave spectrum analyzer designed for field service, routine maintenance, and in-depth troubleshooting. With Keysight-quality measurements in a portable form factor, the N9936A operates from 100 kHz to 14 GHz and can be expanded with numerous optional capabilities to suit specific testing requirements.
Key Features
- Frequency range: 100 kHz to 14 GHz
- Low weight: 6.6 lb (3.0 kg) — lightest microwave handheld spectrum analyzer
- High accuracy: ±0.5 dB spectrum analyzer measurements without warm-up
- Real-time spectrum analysis and spectrogram display for interference location
- Pulse power and CW power measurements with USB power sensor
- Optional tracking generator, power meter, vector network analyzer, and more
Applications
- Field service and maintenance testing
- RF troubleshooting and signal analysis
- Interference detection and localization
- Power and pulse measurements
- Cellular, wireless, and general purpose RF testing with optional software
Specifications
| High Frequency (range) | 10GHz <= 20GHz |
| Low Frequency (range) | 100kHz <= 1MHz |
| Frequency Range | 8.0 - 15.0 GHz |
| Maximum Frequency | 14 GHz |
| Tracking Generator | No |
| Preamplifier | No |
| Noise Floor | -155 dBm |
| Series | N993xA Series |
| Battery Life | 3.5 hrs. |
| Connector Type | N (f) |
| Display | 6.5" LCD Color |
| Includes | Base model includes the cable and antenna analyzer |
| Interface | USB, LAN |
| Minimum Frequency | 100 kHz |
| Number of Ports | 2 |
| Type | Handheld |
| Warranty | 3 Years |
