Keysight N9935A Spectrum Analyzer
Request a quote
Keysight N9935A is a handheld microwave spectrum analyzer with 9 GHz maximum frequency, real-time analysis, and optional tracking generator and power meter capabilities.
Product details
| Model | N9935A |
| Manufacturer | Keysight |
| Category | Spectrum Analyzers |
| Availability | Made to order |
Description
Overview
The Keysight FieldFox N9935A is a handheld microwave spectrum analyzer designed for routine maintenance and in-depth troubleshooting in field environments. Operating from 5 kHz to 9 GHz, it delivers precision measurements without warm-up time and weighs only 6.6 lb (3.0 kg), making it ideal for portable use.
Key Features
- 9 GHz maximum frequency with expandable capability through optional modules
- Real-time spectrum analysis with 10 MHz analysis bandwidth
- Lightweight handheld design at 6.6 lb (3.0 kg)
- Immediate measurement capability without warm-up time
- Intuitive spectrogram display with recording capability
- Optional tracking generator, interference analyzer, and built-in power meter
- Expandable with signal generator, vector voltmeter, and remote control capabilities
Applications
- Field troubleshooting and maintenance
- Signal detection and interference location
- Pulse and power measurements with optional USB power sensor
- Cellular and wireless connectivity analysis
- General-purpose field strength measurement
Specifications
| High Frequency (range) | 1GHz <= 10GHz |
| Low Frequency (range) | 100kHz <= 1MHz |
| Frequency Range | 8.0 - 15.0 GHz |
| Maximum Frequency | 9 GHz |
| Tracking Generator | No |
| Preamplifier | No |
| Noise Floor | -155 dBm |
| Series | N993xA Series |
| Battery Life | 3.5 hrs. |
| Connector Type | N (f) |
| Display | 6.5" LCD Color |
| Includes | Base model includes the cable and antenna analyzer |
| Interface | USB, LAN |
| Minimum Frequency | 100 kHz |
| Number of Ports | 2 |
| Type | Handheld |
| Warranty | 3 Years |
