Keysight N9323C Basic Spectrum Analyzer
Request a quote
Keysight N9323C Basic Spectrum Analyzer offers RF spectrum analysis from 1 MHz to 13.6 GHz with -144 dBm DANL at 1 GHz, tracking generator, and automated task planner.
Product details
| Model | N9323C |
| Manufacturer | Keysight |
| Category | Spectrum Analyzers |
| Availability | Made to order |
Description
Overview
The Keysight N9323C is a basic spectrum analyzer (BSA) offering RF spectrum analysis from 1 MHz to 13.6 GHz. With proven test efficiency and best-in-class usability, it delivers the flexibility to adapt to new requirements and provides straightforward operation for general-purpose spectrum analysis tasks.
The N9323C includes a window limit feature for simultaneous frequency and power limit determinations, enabling one-button pass/fail testing that reduces instrument setup complexity and improves testing efficiency.
Key Features
- Fast RF spectrum analysis from 1 MHz to 13.6 GHz
- Equipped with tracking generator for stimulus-response tests
- Spectrum monitoring feature to identify interfering signals
- AM/FM and ASK/FSK demodulation analysis for IoT transmitter characterization
- Task planner with up to 20 predefined measurements for 95% test setup time reduction
- Window limit feature for one-button pass/fail determination
- Marker demodulation, one-button optimization, and user-definable soft keys
- Support for U2000 Series, U2020 and U2042/44 X-Series USB power sensors
Applications
- EMI troubleshooting and testing
- Radio link monitoring
- Wireless IoT device testing
- Educational applications
- General-purpose RF and microwave measurements
Included Accessories
- USB Cable
- N-BNC Adapter
- BNC Cable
- Power Cord
Specifications
| High Frequency (range) | 10GHz <= 20GHz |
| Low Frequency (range) | 1MHz <= 10MHz |
| Frequency Range | 8.0 - 15.0 GHz |
| Maximum Frequency | 13.6 GHz |
| Noise Floor | -154 dBm |
| Product Type | Benchtop |
| Series | BSA Series |
| Display Type | 6.5" LCD |
| Includes | Spectrum analyzer, USB cable, N-BNC cable, BNC cable, Power cord |
| Input Connector | N-type female, BNC-type female, 10Base-T, USB B plug version 1.1, Mini USB A/B female ersion 1.1, IEEE-488 bus |
| Interface | GPIB, LAN / Ethernet, Other, RF, USB Host, USB |
| Memory | 64 MB |
| Minimum Frequency | 1 MHz |
| Resolution | 10 Hz to 3 MHz |
| Warranty | 5 Years |
