Keysight N9321C Basic Spectrum Analyzer
Keysight N9321C Basic Spectrum Analyzer covers 9 kHz to 4 GHz with -152 dBm sensitivity, resolution bandwidth to 3 MHz, and built-in tracking generator.
Product details
| Model | N9321C |
| Manufacturer | Keysight |
| Category | Spectrum Analyzers |
| Availability | Made to order |
Description
Overview
The Keysight N9321C is a 4 GHz Basic Spectrum Analyzer (BSA) designed for engineers, technicians, and educators who need reliable RF measurements without unnecessary complexity. With frequency coverage from 9 kHz to 4 GHz, the N9321C is well-suited for wireless communications, EMI diagnostics, and general RF testing. The instrument features a 6.5-inch color display and weighs only 7.9 kg, making it suitable for both bench-top and field applications.
The analyzer delivers a minimum displayed noise level of -152 dBm at 1 GHz with preamp on, a resolution bandwidth from 10 Hz to 3 MHz, and a 2 ms non-zero span sweep speed. These specifications enable detailed signal analysis and fast troubleshooting in manufacturing, service, and educational environments.
Key Features
- Frequency range 9 kHz to 4 GHz with DANL of -152 dBm at 1 GHz (preamp on)
- Resolution bandwidth from 10 Hz to 3 MHz for detailed signal analysis
- AM/FM modulation analysis and ASK/FSK demodulation for IoT device characterization
- Up to 18 user-definable softkeys for fast access to customized setups
- Auto-tune feature captures and displays signals automatically
- Window limit enables Pass/Fail testing
- Task planner feature reduces test setup time by 95% with pre-defined measurements
- Built-in VSWR bridge and tracking generator (5 MHz to 7 GHz)
- Multiple interfaces: LAN, USB, and optional GPIB (opt. G01)
- Upgradable to precision frequency reference (opt. PFR) with ±0.1 ppm annual aging
- Portable design at 7.9 kg (17.4 lbs) with ruggedized construction
- SCPI command compatibility with Keysight ESA and X-series instruments
Applications
- Wireless communication testing and channel analysis
- EMI/RFI troubleshooting and compliance measurement
- Filter and amplifier tuning and verification
- Antenna testing and optimization
- Cable diagnostics with distance-to-fault capability
- Radio link monitoring and interference detection
- Wireless IoT device testing and characterization
- Educational demonstrations and student instruction
Included Accessories
- N9321C BSA spectrum analyzer
- Calibration certificate
- USB cable
- N-BNC adapter
- BNC cable
- Country-specific power cord
Specifications
| High Frequency (range) | 1GHz <= 10GHz |
| Low Frequency (range) | 1kHz <= 100kHz |
| Frequency Range | 0.5 - 4.0 GHz |
| Maximum Frequency | 4 GHz |
| Noise Floor | -162 dBm |
| Product Type | Benchtop |
| Series | BSA Series |
| Display Type | 6.5" LCD |
| Includes | Calibration Certificate, USB Cable, N-BNC adapter, BNC cable, Power Cord |
| Input Connector | N-type female, BNC-type female, 100Base-T, USB B plug version 1.1, USB Mini-AB female version 1.1, IEEE-488 bus |
| Interface | GPIB, LAN / Ethernet, Other, RF, USB Host, USB |
| Memory | 64 MB |
| Minimum Frequency | 9 kHz |
| Resolution | 10 Hz to 3 MHz |
| Warranty | 5 Years |
