Keysight M9391A Vector Signal Analyzer
Request a quote
Keysight M9391A is a modular PXI vector signal analyzer from 1 MHz to 3/6 GHz with up to 160 MHz bandwidth and ±0.45 dB amplitude accuracy for RF component testing.
Product details
| Model | M9391A |
| Manufacturer | Keysight |
| Category | Spectrum Analyzers |
| Availability | Made to order |
Description
Overview
The Keysight M9391A is a modular PXI vector signal analyzer engineered for demanding RF and wireless component testing. Supporting frequency ranges from 1 MHz to 3 GHz or 6 GHz with up to 8 time-synchronous, phase-coherent channels, it combines raw hardware speed with X-Series measurement applications for proven signal analysis results. The system delivers exceptional amplitude accuracy and noise performance, enabling faster RF component characterization and test convergence.
Key Features
- Frequency range: 1 MHz to 3 GHz or 6 GHz
- Analysis bandwidth: 40 MHz standard, with 100 MHz and 160 MHz options
- Up to 8 time-synchronous, phase-coherent channels for multi-channel testing
- Absolute amplitude accuracy of ±0.45 dB
- DANL: -157 dBm displayed average noise level
- Phase noise: -119 dBc/Hz @ 1 GHz, 10 kHz offset
- Hardware-accelerated power, spectrum, and IQ measurements
- Support for cellular (GSM, CDMA, W-CDMA, LTE) and wireless (802.11) standards
Applications
- RF component testing and characterization
- Cellular communications standards validation
- Wireless connectivity standards testing
- Advanced signal format analysis via 89600 VSA software
Specifications
| High Frequency (range) | 1GHz <= 10GHz |
| Low Frequency (range) | 100kHz <= 1MHz |
