TDK-Lambda Z650-0.64-IS510-U DC Power Supply
Request a quote
TDK-Lambda Z650-0.64-IS510-U delivers 650V at 0.64A (416W) with isolated analog voltage programming interface, USB/RS-232 communication, and constant voltage/current modes.
Product details
| Model | Z650-0.64-IS510-U |
| Manufacturer | TDK-Lambda |
| Category | Single Output DC Supplies |
| Availability | Made to order |
Description
Overview
The TDK-Lambda Z650-0.64-IS510-U is a high-performance DC power supply delivering 650V at 0.64A (416W maximum). This unit is equipped with an isolated analog voltage programming interface, making it ideal for precision automated test systems and laboratory applications requiring remote voltage control and monitoring.
Key Features
- Single output: 650V at 0.64A (416W max)
- Isolated analog voltage programming interface (IS510)
- Built-in USB, RS-232, and RS-485 serial interfaces
- Constant voltage and constant current operating modes
- User-programmable output signal pins
- Bench or rack-mount operation (2U height)
- Wide input voltage range: 85–265 VAC with active power factor correction
- Front panel output terminals available (optional)
- Parallel operation capability with active current sharing
- 5-year manufacturer warranty
Applications
- Automated test and measurement systems
- High-voltage equipment testing
- Industrial process control
- Research and laboratory applications
Specifications
| Voltage Range Selector | 500-999 |
| Output Voltage | 650 V |
| Current Range Selector | 0-2.49 |
| Output Current | 0.64 A |
| Power Range Selector | 200-499 |
| Power Rating | 416 W |
| Mounting Type | Bench Top |
| Input Voltage | 85-265 VAC |
| Series | Z+ Series |
| Display | Digital |
| Interface | USB,RS-232,RS-485 |
| Number of Outputs | Single Output |
| Programmable | Yes |
| Rack Space | 2U |
| Special Features | Isolated Analog Voltage Control |
