Keithley 2302 Battery Simulator

Overview

The Keithley 2302 is a single-channel battery simulator power supply designed for development and testing of portable, battery-operated devices such as cellular phones, cordless phones, and mobile radios. This precision DC power supply features ultrafast transient response, allowing output characteristics to match actual batteries with exceptional accuracy.

The 2302 employs a unique variable output resistance design that enables the voltage output to emulate a battery's response, including its internal resistance characteristics. This capability allows stable voltage outputs even when a device-under-test makes rapid transitions from standby (low current) to RF transmission (high current) states, making it ideal for comprehensive battery performance simulation.

Key Features

• Ultrafast response to transient load currents with output returning to within 100 mV of set voltage in 40 µs or less
• Variable output resistance for simulating battery internal resistance and response characteristics
• Pulse peak, average, and baseline load current measurements for comprehensive load analysis
• 100nA DC current sensitivity for monitoring low sleep mode currents
• Current step measure function for measuring load current at each device operational state
• Sink up to 3A to simulate discharged rechargeable batteries for charger testing
• Open sense lead detection for system integrity verification
• Built-in digital voltmeter measuring signals from -5V to +30V DC with high accuracy

Applications

• Portable device battery-operated circuit development and testing
• Battery charger and charge control circuitry verification
• RF device transient load simulation and performance analysis
• Low power consumption monitoring and sleep mode current measurement
