TDK-Lambda Z650-0.32-U DC Power Supply
Request a quote
TDK-Lambda Z650-0.32-U delivers 650V at 0.32A in a compact 2U form factor with programmable control and multiple communication interfaces for lab and industrial applications.
Product details
| Model | Z650-0.32-U |
| Manufacturer | TDK-Lambda |
| Category | Single Output DC Supplies |
| Availability | Made to order |
Description
Overview
The TDK-Lambda Z+ Series is a line of high-performance, programmable DC power supplies designed for demanding laboratory and industrial applications. The Z650-0.32-U model delivers 650V output with 0.32A capacity and 208W power in a space-efficient 2U form factor. Featuring a wide input voltage range of 85-265 VAC with active power factor correction, these supplies provide stable operation across diverse electrical environments worldwide.
Key Features
- 650V output with 0.32A current capacity and 208W power
- High power density in compact 2U form factor (3.5 inches high)
- Wide input voltage range: 85-265 VAC continuous
- Active power factor correction (0.99 typical)
- Built-in USB, RS-232, and RS-485 communication interfaces
- Optional LAN, GPIB, and isolated analog programming interfaces
- Constant voltage and constant current operating modes
- Programmable output sequencing and arbitrary function generation
- Last-setting memory for automatic parameter recovery
- Front panel controls with LED status indicators
- Optional front panel output terminals for models up to 60V or 24A
- UL listed and CE marked
- Five-year warranty
Applications
- Laboratory test and measurement equipment
- Automated manufacturing and quality control
- Telecommunications and electronics testing
- Research and development
- Parallel operation with active current sharing capability
Specifications
| Voltage Range Selector | 500-999 |
| Output Voltage | 650 V |
| Current Range Selector | 0-2.49 |
| Output Current | 0.32 A |
| Power Range Selector | 200-499 |
| Power Rating | 208 W |
| Mounting Type | Bench Top |
| Input Voltage | 85-265 VAC |
| Series | Z+ Series |
| Display | Digital |
| Interface | USB,RS-232,RS-485 |
| Number of Outputs | Single Output |
| Programmable | Yes |
| Rack Space | 2U |
| Special Features | Constant Current, Constant Voltage, Master/Slave Modes |
