TDK-Lambda Z650-0.32-LAN-U DC Power Supply
Request a quote
TDK-Lambda Z650-0.32-LAN-U is a programmable DC power supply with 650V output, 0.32A capacity, and integrated LAN interface for remote control and monitoring.
Product details
| Model | Z650-0.32-LAN-U |
| Manufacturer | TDK-Lambda |
| Category | Single Output DC Supplies |
| Availability | Made to order |
Description
Overview
The TDK-Lambda Z650-0.32-LAN-U is a high-performance programmable DC power supply featuring 650V output and 0.32A capacity. Designed for applications requiring precise voltage and current control, this unit combines bench and rack-mount flexibility with integrated LAN connectivity for remote monitoring and control. It operates reliably across a wide input voltage range of 85-265 VAC with selectable 115-230 VAC operation.
Key Features
- 650V output with 0.32A current capacity and 208W power
- Integrated LAN interface for remote monitoring and control
- Built-in USB, RS-232, and RS-485 communication interfaces
- Constant voltage and constant current operating modes
- User-programmable output signal pins
- Front panel controls for local parameter adjustment and status monitoring
- 2U compact form factor (bench or rack-mount capable)
- Wide input voltage range: 85-265 VAC
- Five-year manufacturer warranty
Applications
- Laboratory test and measurement equipment
- Industrial automation and control systems
- Telecommunications equipment
- Research and development
Specifications
| Voltage Range Selector | 500-999 |
| Output Voltage | 650 V |
| Current Range Selector | 0-2.49 |
| Output Current | 0.32 A |
| Power Range Selector | 200-499 |
| Power Rating | 208 W |
| Mounting Type | Bench Top |
| Input Voltage | 85-265 VAC |
| Series | Z+ Series |
| Display | Digital |
| Interface | USB,LAN,RS-232,RS-485 |
| Number of Outputs | Single Output |
| Programmable | Yes |
| Rack Space | 2U |
| Special Features | Constant Current, Constant Voltage, Master/Slave Modes |
