TDK-Lambda Z60-3.5-U DC Power Supply

Overview

The TDK-Lambda Z60-3.5-U is a 210W single output DC power supply part of the high-performance Z+ Series. It delivers 60V at 3.5A with wide input voltage operation (85–265 VAC), active power factor correction (0.99 typical), and support for parallel operation of up to six units with active current sharing. Built-in USB, RS-232, and RS-485 interfaces enable flexible local and remote control, with optional LAN and GPIB interfaces available for network or GPIB control systems.

The Z+ Series supplies feature user-friendly front panel controls for setting output parameters, protection levels (over-voltage, under-voltage, foldback), and remote monitoring through analog or digital communication. Output voltage and current are continuously displayed with LED status indicators showing complete operating status.

Key Features

• 60V/3.5A output, 210W maximum power
• Built-in USB, RS-232, and RS-485 communication interfaces
• Optional LAN or GPIB interfaces (factory-installed)
• Active power factor correction (0.99 typical)
• Wide input range: 85–265 VAC (selectable 115/230 VAC)
• Constant voltage and constant current operation modes
• User-programmable output signal pins and arbitrary functions
• Programmable output sequencing for multi-supply systems
• Parallel operation capability: up to 6 units with active current sharing
• Front panel output jacks available (optional -L or -L2 suffix)
• Bench or rack-mount configurations
• 2U height, 1/6 to 1/4 rack width depending on options
• 5-year warranty
• UL listed (USA/Canada), CE marked

Applications

• Automated test equipment (ATE) and production testing
• Laboratory and bench power applications
• Semiconductor device characterization and testing
• Multi-channel test systems and parallel configurations
• Telecommunications and networking equipment testing
• Industrial process control and automation
• Research and development applications
