TDK-Lambda Z60-3.5-LAN-U DC Power Supply
Request a quote
TDK-Lambda Z60-3.5-LAN-U delivers 210W at 60V/3.5A with built-in LAN, USB, RS-232, and RS-485 interfaces for remote monitoring and control.
Product details
| Model | Z60-3.5-LAN-U |
| Manufacturer | TDK-Lambda |
| Category | Single Output DC Supplies |
| Availability | Made to order |
Description
Overview
The TDK-Lambda Z60-3.5-LAN-U is a 210W single output DC power supply providing 60V at 3.5A. Part of the Z+ Series, it includes built-in USB, RS-232, RS-485, and LAN interfaces for flexible remote control and monitoring. The supply operates from a wide AC input range of 85–265 VAC with selectable 115/230 VAC operation, supporting both bench and rack-mount configurations.
Key Features
- 60V, 3.5A output (210W maximum)
- Built-in USB, RS-232, RS-485, and LAN interfaces
- Constant voltage and constant current operation modes
- User-programmable output signal pins
- Wide input voltage range: 85–265 VAC
- Selectable 115/230 VAC operation
- Bench or rack-mount configurations
- 2U form factor
- 5-year warranty
- UL and CE certified
Applications
- Laboratory testing and research
- Industrial process control and automation
- Semiconductor device testing and characterization
- Telecommunications and networking equipment
- Automated test equipment (ATE) systems
Specifications
| Voltage Range Selector | 50-99.9 |
| Output Voltage | 60 V |
| Current Range Selector | 2.5-4.9 |
| Output Current | 3.5 A |
| Power Range Selector | 200-499 |
| Power Rating | 210 W |
| Mounting Type | Bench Top |
| Input Voltage | 85-265 VAC |
| Series | Z+ Series |
| Display | Digital |
| Interface | USB,LAN,RS-232,RS-485 |
| Number of Outputs | Single Output |
| Programmable | Yes |
| Rack Space | 2U |
| Special Features | Constant Current, Constant Voltage, Master/Slave Modes |
