TDK-Lambda Z60-3.5-LAN-L-U DC Power Supply
Request a quote
TDK-Lambda Z60-3.5-LAN-L-U is a 60V, 3.5A isolated DC power supply with LAN, front panel output jacks, USB, RS-232, RS-485 for bench or rack mount.
Product details
| Model | Z60-3.5-LAN-L-U |
| Manufacturer | TDK-Lambda |
| Category | Single Output DC Supplies |
| Availability | Made to order |
Description
Overview
The TDK-Lambda Z60-3.5-LAN-L-U is an isolated DC power supply delivering 60V at 3.5A (210W) with selectable 115-230VAC input, LAN interface, and front panel output jacks. Featuring a compact 2U chassis, it operates in constant current or voltage mode and is ideal for networked laboratory and industrial applications.
Key Features
- Output: 60V, 3.5A (210W)
- LAN (Local Area Network) interface for remote control
- Front panel output jacks (4mm binding post, rated to 60V/24A max)
- Constant Current or Voltage modes
- Built-in USB, RS-232, and RS-485 interfaces
- User-programmable output signal pins
- Selectable 115-230VAC input (85-265VAC operating range)
- 2U high, bench or rack mount
- 5-year warranty
Applications
- Laboratory power systems with network integration
- Industrial test equipment with remote control
- Networked automated control systems
- Research and development facilities
Optional Interfaces
- GPIB (IEEE 488)
- Current Programming Interface (IS420)
- Voltage Programming Interface (IS510)
Specifications
| Voltage Range Selector | 50-99.9 |
| Output Voltage | 60 V |
| Current Range Selector | 2.5-4.9 |
| Output Current | 3.5 A |
| Power Range Selector | 200-499 |
| Power Rating | 210 W |
| Mounting Type | Bench Top |
| Input Voltage | 85-265 VAC |
| Series | Z+ Series |
| Display | Digital |
| Interface | USB,LAN,RS-232,RS-485 |
| Number of Outputs | Single Output |
| Programmable | Yes |
| Rack Space | 2U |
| Special Features | Front Panel Binding Posts |
