TDK-Lambda Z60-10-U DC Power Supply

Overview

The TDK-Lambda Z60-10-U is a 600W single-output DC power supply delivering 60V at 10A. Part of the Z+ Series of high-performance switching power supplies, it features wide-range input (85-265 VAC continuous), active power factor correction (0.99 typical), and continuous display of output voltage and current with LED status indicators. The front panel provides manual control for output parameters and protection settings, while the rear panel includes connections for remote control and monitoring via analog signals or serial communication.

The Z60-10-U integrates built-in USB, RS-232, and RS-485 interfaces for communication and control. Optional interfaces include LAN and GPIB for integration into larger systems. Up to 31 units can be networked together using RS-485 or LAN communication. The unit operates in constant current or voltage modes and includes a five-year warranty with UL and CE certification.

Key Features

• 600W power output with 60V/10A rating
• Wide AC input range: 85-265 VAC continuous operation
• Active power factor correction (0.99 typical)
• Built-in USB, RS-232, and RS-485 serial interfaces
• Optional LAN and GPIB interfaces for system integration
• Front panel voltage and current display with LED status indicators
• Adjustable output parameters and protection levels (OVP, UVP, Foldback)
• Parallel operation capability with active current sharing for up to six units
• Arbitrary function and output sequencing support
• Constant current or voltage operation modes
• Optional front panel output terminals rated to 60V/24A maximum
• UL listed for USA and Canada, CE marked
• Five-year warranty

Applications

• Laboratory and bench-top power testing
• Industrial equipment power supply applications
• Research and development environments
• Production line equipment and automated systems
• Multi-unit parallel systems for higher power delivery
• Remote monitoring and control applications
