TDK-Lambda Z60-10-LAN-L-U DC Power Supply
Request a quote
TDK-Lambda Z60-10-LAN-L-U is a 600W single-output DC power supply with 60V/10A output, integrated LAN interface, and front panel output jacks.
Product details
| Model | Z60-10-LAN-L-U |
| Manufacturer | TDK-Lambda |
| Category | Single Output DC Supplies |
| Availability | Made to order |
Description
Overview
The TDK-Lambda Z60-10-LAN-L-U is a single-output DC power supply with integrated LAN interface for networked control and monitoring. It delivers 600W at 60V/10A and features front panel output jacks for convenient bench or rack-mount operation with constant voltage and current modes.
Key Features
- Constant voltage and constant current modes
- Local Area Network (LAN) interface for remote control and monitoring
- Built-in USB, RS-232, and RS-485 interfaces
- Front panel output jacks (4mm binding post style)
- User-programmable output signal pins
- Selectable 115–230VAC input with universal range (85–265VAC)
- 2U rack height
- 5-year warranty
Applications
- Remote networked power system control
- Rack-mount automated test equipment
- Multi-unit distributed power management
Specifications
| Voltage Range Selector | 50-99.9 |
| Output Voltage | 60 V |
| Current Range Selector | 10-19.9 |
| Output Current | 10 A |
| Power Range Selector | 500-999 |
| Power Rating | 600 W |
| Mounting Type | Bench Top |
| Input Voltage | 85-265 VAC |
| Series | Z+ Series |
| Display | Digital |
| Interface | USB,LAN,RS-232,RS-485 |
| Number of Outputs | Single Output |
| Programmable | Yes |
| Rack Space | 2U |
| Special Features | Front Panel Binding Posts |
