TDK-Lambda Z60-10-L-U DC Power Supply
Request a quote
TDK-Lambda Z60-10-L-U is a 600W single-output DC power supply with 60V/10A output, constant voltage/current modes, and built-in USB, RS-232, and RS-485 interfaces.
Product details
| Model | Z60-10-L-U |
| Manufacturer | TDK-Lambda |
| Category | Single Output DC Supplies |
| Availability | Made to order |
Description
Overview
The TDK-Lambda Z60-10-L-U is a single-output DC power supply designed for bench or rack mounting applications. It delivers 600W of power at 60V/10A with constant voltage and constant current operational modes. The supply features user-programmable output signal pins and front panel output jacks for convenient connections.
Key Features
- Constant voltage and constant current modes
- Built-in USB, RS-232, and RS-485 interfaces
- User-programmable output signal pins
- Front panel output jacks (4mm binding post style)
- Selectable 115–230VAC input with universal range (85–265VAC)
- 2U rack height
- 5-year warranty
Optional Interfaces
- GPIB (IEEE) interface
- LAN (Local Area Network) interface
- Isolated voltage or current programming interfaces
Applications
- Bench testing and development
- Rack-mount system integration
- Automated test equipment
Specifications
| Voltage Range Selector | 50-99.9 |
| Output Voltage | 60 V |
| Current Range Selector | 10-19.9 |
| Output Current | 10 A |
| Power Range Selector | 500-999 |
| Power Rating | 600 W |
| Mounting Type | Bench Top |
| Input Voltage | 85-265 VAC |
| Series | Z+ Series |
| Display | Digital |
| Interface | USB,RS-232,RS-485 |
| Number of Outputs | Single Output |
| Programmable | Yes |
| Rack Space | 2U |
| Special Features | Front Panel Binding Posts |
