TDK-Lambda Z36-6-U DC Power Supply
Request a quote
TDK-Lambda Z36-6-U provides 36V/6A/216W output with wide AC input (85-265VAC), USB/RS-232/RS-485 interfaces, constant current/voltage modes, and 5-year warranty.
Product details
| Model | Z36-6-U |
| Manufacturer | TDK-Lambda |
| Category | Single Output DC Supplies |
| Availability | Made to order |
Description
Overview
The TDK-Lambda Z36-6-U is a programmable DC power supply from the Z+ Series of high-performance switching power supplies. It delivers 36V output at up to 6A (216W) with a wide AC input range (85-265VAC), active power factor correction, and support for parallel operation with current sharing. The power supply features constant current and constant voltage modes with user-programmable parameters and extensive remote control capabilities.
Key Features
- Output: 36V, 6A, 216W
- Input voltage range: 85-265VAC continuous, selectable 115-230VAC
- High power density in 2U (3.5" high) enclosure
- Active power factor correction (0.99 typical)
- Built-in interfaces: USB, RS-232, RS-485
- Constant current and constant voltage modes
- User-programmable output signal pins
- Arbitrary function generation and output sequencing
- Last-setting memory
- Parallel operation with active current sharing (up to 6 units)
- 5-year warranty
- UL listed (USA and Canada), CE marked
Applications
- Laboratory and test equipment
- Industrial automation and control systems
- Power system research and development
- Prototype development and design validation
Specifications
| Voltage Range Selector | 30-49.9 |
| Output Voltage | 36 V |
| Current Range Selector | 5-9.9 |
| Output Current | 6 A |
| Power Range Selector | 200-499 |
| Power Rating | 216 W |
| Mounting Type | Bench Top |
| Input Voltage | 85-265 VAC |
| Series | Z+ Series |
| Display | Digital |
| Interface | USB,RS-232,RS-485 |
| Number of Outputs | Single Output |
| Programmable | Yes |
| Rack Space | 2U |
| Special Features | Constant Current, Constant Voltage, Master/Slave Modes |
