TDK-Lambda Z36-6-LAN-L-U DC Power Supply
Request a quote
TDK-Lambda Z36-6-LAN-L-U provides 36V/6A/216W output with wide AC input (85-265VAC), USB/RS-232/RS-485/LAN interfaces, constant current/voltage modes, and 5-year warranty.
Product details
| Model | Z36-6-LAN-L-U |
| Manufacturer | TDK-Lambda |
| Category | Single Output DC Supplies |
| Availability | Made to order |
Description
Overview
The TDK-Lambda Z36-6-LAN-L-U is a programmable DC power supply from the Z+ Series that delivers 36V output at up to 6A (216W). It features a wide input voltage range (85-265VAC), making it suitable for bench-top or rack-mount applications. The power supply supports constant current and constant voltage modes with user-programmable settings and remote control capabilities via multiple interfaces including LAN.
Key Features
- Output: 36V, 6A, 216W
- Input voltage range: 85-265VAC continuous, selectable 115-230VAC
- Built-in interfaces: USB, RS-232, RS-485, LAN
- Front panel output jacks (4mm binding posts, up to 60V/24A max)
- Constant current and constant voltage modes
- User-programmable output signal pins
- 2U high, suitable for bench or rack mounting
- 5-year warranty
- UL listed (USA and Canada), CE marked
Applications
- Laboratory and test equipment
- Industrial automation and control systems
- Power system research and development
- Prototype development and design validation
Specifications
| Voltage Range Selector | 30-49.9 |
| Output Voltage | 36 V |
| Current Range Selector | 5-9.9 |
| Output Current | 6 A |
| Power Range Selector | 200-499 |
| Power Rating | 216 W |
| Mounting Type | Bench Top |
| Input Voltage | 85-265 VAC |
| Series | Z+ Series |
| Display | Digital |
| Interface | USB,LAN,RS-232,RS-485 |
| Number of Outputs | Single Output |
| Programmable | Yes |
| Rack Space | 2U |
| Special Features | Front Panel Binding Posts |
