TDK-Lambda Z36-24-U DC Power Supply
Request a quote
TDK-Lambda Z36-24-U is an 864W switching power supply delivering 36V at 24A with wide AC input (85-265VAC), power factor correction, and USB/RS-232/RS-485 interfaces.
Product details
| Model | Z36-24-U |
| Manufacturer | TDK-Lambda |
| Category | Single Output DC Supplies |
| Availability | Made to order |
Description
Overview
The TDK-Lambda Z36-24-U is a high-performance switching power supply from the Z+ Series, delivering 36V at 24A (864W). It features wide input voltage range (85-265 VAC continuous) with active power factor correction (0.99 typical), making it suitable for worldwide use. The supply operates in constant voltage or constant current modes with front panel controls for setting output parameters and protection levels.
Key Features
- Wide input voltage range: 85-265 VAC continuous with power factor correction (0.99)
- Output: 36V, 24A, 864W with continuously displayed voltage and current
- Built-in USB, RS-232, and RS-485 serial communication interfaces
- Optional LAN, GPIB, and Isolated Analog programming interfaces
- Constant voltage or constant current operating modes
- Parallel operation with active current sharing (up to 6 units)
- Front panel controls with LED status indicators
- Over-voltage, under-voltage, and foldback protection
- Arbitrary function and output sequencing capabilities
- 5-year warranty, UL listed (USA/Canada), CE marked
Applications
- Laboratory and test bench power applications
- Industrial process control and automation
- R&D and product development environments
- System integration and multi-unit parallel configurations
Specifications
| Voltage Range Selector | 30-49.9 |
| Output Voltage | 36 V |
| Current Range Selector | 20-29.9 |
| Output Current | 24 A |
| Power Range Selector | 500-999 |
| Power Rating | 864 W |
| Mounting Type | Bench Top |
| Input Voltage | 85-265 VAC |
| Series | Z+ Series |
| Display | Digital |
| Interface | USB,RS-232,RS-485 |
| Number of Outputs | Single Output |
| Programmable | Yes |
| Rack Space | 2U |
| Special Features | Constant Current, Constant Voltage, Master/Slave Modes |
