TDK-Lambda Z36-24-LAN-U DC Power Supply
Request a quote
TDK-Lambda Z36-24-LAN-U is a 36V/24A isolated DC power supply with LAN network interface and USB, RS-232, RS-485 connectivity.
Product details
| Model | Z36-24-LAN-U |
| Manufacturer | TDK-Lambda |
| Category | Single Output DC Supplies |
| Availability | Made to order |
Description
Overview
The TDK-Lambda Z36-24-LAN-U is an isolated DC power supply from the Z+ series, designed for network-integrated automated test systems and production environments. This 2U high unit delivers 36V/24A output with the LAN interface as the primary connectivity option for remote monitoring and control. It also provides USB, RS-232, and RS-485 interfaces for flexible system integration and fallback connectivity.
Key Features
- LAN (Local Area Network) interface for network-based remote control and monitoring
- Built-in USB, RS-232, and RS-485 communication interfaces for backup connectivity
- Constant voltage and constant current operating modes
- User programmable output control signal pins
- Bench and rack mount configuration options
- Selectable 115-230VAC input (operates 85-265VAC range)
- 5-year manufacturer warranty
Applications
- Networked automated test equipment and production systems
- Remote power management in centralized test facilities
- Industrial automation requiring network-based control
- Equipment integration into distributed control architectures
Specifications
| Voltage Range Selector | 30-49.9 |
| Output Voltage | 36 V |
| Current Range Selector | 20-29.9 |
| Output Current | 24 A |
| Power Range Selector | 500-999 |
| Power Rating | 864 W |
| Mounting Type | Bench Top |
| Input Voltage | 85-265 VAC |
| Series | Z+ Series |
| Display | Digital |
| Interface | USB,LAN,RS-232,RS-485 |
| Number of Outputs | Single Output |
| Programmable | Yes |
| Rack Space | 2U |
| Special Features | Constant Current, Constant Voltage, Master/Slave Modes |
