TDK-Lambda Z36-24-L-U DC Power Supply
Request a quote
TDK-Lambda Z36-24-L-U is a 36V/24A isolated DC power supply with front panel 4mm binding post connectors and USB, RS-232, RS-485 interfaces.
Product details
| Model | Z36-24-L-U |
| Manufacturer | TDK-Lambda |
| Category | Single Output DC Supplies |
| Availability | Made to order |
Description
Overview
The TDK-Lambda Z36-24-L-U is an isolated DC power supply from the Z+ series, featuring front panel 4mm binding post connectors for direct equipment connections. This 2U high unit provides 36V/24A output with flexible bench or rack mounting. The built-in communication interfaces support USB, RS-232, and RS-485 for integration with test systems and automated control equipment.
Key Features
- Front panel 4mm binding post output connectors for direct connections up to 60V/24A
- Built-in USB, RS-232, and RS-485 communication interfaces
- Constant voltage and constant current operating modes
- User programmable output control signal pins
- Bench and rack mount configuration options
- Selectable 115-230VAC input (operates 85-265VAC range)
- 5-year manufacturer warranty
Applications
- Laboratory benchtop testing and troubleshooting
- Equipment commissioning and development work
- Production and field service applications
- Applications benefiting from convenient front panel access
Specifications
| Voltage Range Selector | 30-49.9 |
| Output Voltage | 36 V |
| Current Range Selector | 20-29.9 |
| Output Current | 24 A |
| Power Range Selector | 500-999 |
| Power Rating | 864 W |
| Mounting Type | Bench Top |
| Input Voltage | 85-265 VAC |
| Series | Z+ Series |
| Display | Digital |
| Interface | USB,RS-232,RS-485 |
| Number of Outputs | Single Output |
| Programmable | Yes |
| Rack Space | 2U |
| Special Features | Front Panel Binding Posts |
