TDK-Lambda Z320-2-U DC Power Supply
Request a quote
TDK-Lambda Z320-2-U DC power supply delivers 320V/2A output with USB, RS-232, and RS-485 interfaces for laboratory, industrial, and automated testing applications.
Product details
| Model | Z320-2-U |
| Manufacturer | TDK-Lambda |
| Category | Single Output DC Supplies |
| Availability | Made to order |
Description
Overview
The TDK-Lambda Z320-2-U is a programmable DC power supply engineered for laboratory, industrial, and automated testing environments. It delivers 320V output at up to 2A, providing 640W of power. The unit features built-in USB, RS-232, and RS-485 serial interfaces for flexible connectivity and system integration. Available in both benchtop and rack-mount configurations (2U form factor), it offers a practical solution for diverse test and measurement applications.
Key Features
- Single output: 320V, 2A maximum current, 640W power
- Built-in USB, RS-232, and RS-485 serial interfaces
- Constant voltage and constant current operating modes
- User-programmable output signal pins for custom control logic
- 2U high form factor: bench or rack mount configuration
- Wide input voltage acceptance: 85-265VAC (user-selectable 115-230VAC)
- Five-year manufacturer warranty
- Optional GPIB, LAN, and isolated analog interfaces available
Applications
- Laboratory power supply for electronics testing and device characterization
- Industrial automation and control system testing
- Automated test equipment (ATE) system integration
- Research and development facilities
Specifications
| Voltage Range Selector | 300-499 |
| Output Voltage | 320 V |
| Current Range Selector | 0-2.49 |
| Output Current | 2 A |
| Power Range Selector | 500-999 |
| Power Rating | 640 W |
| Mounting Type | Bench Top |
| Input Voltage | 85-265 VAC |
| Series | Z+ Series |
| Display | Digital |
| Interface | USB,RS-232,RS-485 |
| Number of Outputs | Single Output |
| Programmable | Yes |
| Rack Space | 2U |
| Special Features | Constant Current, Constant Voltage, Master/Slave Modes |
