TDK-Lambda Z320-2-LAN-U DC Power Supply
Request a quote
TDK-Lambda Z320-2-LAN-U DC power supply offers 320V/2A output with integrated LAN, USB, RS-232, and RS-485 interfaces for laboratory and automated test systems.
Product details
| Model | Z320-2-LAN-U |
| Manufacturer | TDK-Lambda |
| Category | Single Output DC Supplies |
| Availability | Made to order |
Description
Overview
The TDK-Lambda Z320-2-LAN-U is a programmable DC power supply designed for laboratory, industrial testing, and automated system integration. It provides 320V output at up to 2A, delivering 640W of power. The unit combines benchtop convenience with rack-mount capability in a 2U form factor and features integrated LAN connectivity for remote operation and control from networked systems. Additional optional interfaces including GPIB, isolated analog inputs, and other configurations are available to suit specific application requirements.
Key Features
- Single output: 320V, 2A maximum current, 640W power
- Integrated LAN interface for network-based remote control
- Built-in USB, RS-232, and RS-485 serial interfaces
- Constant voltage and constant current operating modes
- User-programmable output signal pins for custom control logic
- 2U high form factor: bench or rack mount configuration
- Wide input voltage acceptance: 85-265VAC (user-selectable 115-230VAC)
- Five-year manufacturer warranty
Applications
- Laboratory power supply for electronics testing and characterization
- Industrial automation and control system testing
- Automated test equipment (ATE) system integration
- Research and development bench work
Specifications
| Voltage Range Selector | 300-499 |
| Output Voltage | 320 V |
| Current Range Selector | 0-2.49 |
| Output Current | 2 A |
| Power Range Selector | 500-999 |
| Power Rating | 640 W |
| Mounting Type | Bench Top |
| Input Voltage | 85-265 VAC |
| Series | Z+ Series |
| Display | Digital |
| Interface | USB,LAN,RS-232,RS-485 |
| Number of Outputs | Single Output |
| Programmable | Yes |
| Rack Space | 2U |
| Special Features | Constant Current, Constant Voltage, Master/Slave Modes |
