TDK-Lambda Z320-0.65-U DC Power Supply

Overview

The TDK-Lambda Z320-0.65-U is part of the Z+ series of high-performance DC power supplies. This 208W model delivers a single 320V/0.65A output with comprehensive built-in communication interfaces. The Z+ series features wide input voltage range support, active power factor correction, and configurable mounting options, making these supplies ideal for laboratory, test, and industrial applications requiring flexible high-voltage power management.

Key Features

• Single output: 320V at 0.65A, 208W power
• Wide input voltage range: 85–265VAC (selectable 115-230VAC)
• Part of Z+ series with 33 models from 10V to 650V output
• Built-in USB, RS-232, and RS-485 serial interfaces
• Constant current or constant voltage operating modes
• Active power factor correction (0.99 typical)
• User-programmable output signal pins and sequencing
• Parallel operation with active current sharing (up to 6 units)
• Bench or rack mount configuration
• Optional front panel terminals, GPIB, LAN, or isolated analog interfaces
• Arbitrary function generation capability
• 5-year warranty
• UL listed for USA and Canada, CE marked

Applications

• Laboratory power supply and test systems
• Automated test equipment (ATE) systems
• Industrial component testing and validation
• Multi-unit high-voltage applications with current sharing

Z+ Series Options

• Front panel terminals (L or L2) for outputs to 60V, 24A maximum
• GPIB interface (IEEE) for automated test system integration
• LAN interface for networked control
• Isolated analog programming: voltage control (IS510) or current control (IS420)
