TDK-Lambda Z20-40-L-U DC Power Supply
Request a quote
TDK-Lambda Z20-40-L-U — 20V/40A/800W DC power supply with front panel 4mm binding post output jacks, USB/RS-232/RS-485 interfaces, and 5-year warranty.
Product details
| Model | Z20-40-L-U |
| Manufacturer | TDK-Lambda |
| Category | Single Output DC Supplies |
| Availability | Made to order |
Description
Overview
The TDK-Lambda Z20-40-L-U is a 20V, 40A, 800W DC power supply with front panel 4mm binding post output connectors. Designed for laboratory and industrial applications, it combines convenient front-panel connections with multiple communication interfaces for flexible system integration.
Key Features
- 20V/40A output (800W maximum)
- Front panel 4mm binding post output jacks (L option)
- Built-in USB, RS-232 & RS-485 communication interfaces
- Constant current and constant voltage operating modes
- User-programmable output signal pins
- Selectable input voltage 115-230VAC (85-265VAC operating range)
- 2U rack-mount height with bench mounting capability
- 5-year manufacturer warranty
Applications
- Laboratory test benches and research systems
- Industrial control and power distribution
- Equipment testing and commissioning
- Educational and training applications
- Field service and troubleshooting
Specifications
| Voltage Range Selector | 20-29.9 |
| Output Voltage | 20 V |
| Current Range Selector | 30-49.9 |
| Output Current | 40 A |
| Power Range Selector | 500-999 |
| Power Rating | 800 W |
| Mounting Type | Bench Top |
| Input Voltage | 85-265 VAC |
| Series | Z+ Series |
| Display | Digital |
| Interface | USB,RS-232,RS-485 |
| Number of Outputs | Single Output |
| Programmable | Yes |
| Rack Space | 2U |
| Special Features | Front Panel Binding Posts |
