TDK-Lambda Z20-30-L-U DC Power Supply
Request a quote
TDK-Lambda Z20-30-L-U is a 20V/30A DC power supply with front-panel binding post output jacks for direct connections, USB, RS-232/RS-485, and dual mounting.
Product details
| Model | Z20-30-L-U |
| Manufacturer | TDK-Lambda |
| Category | Single Output DC Supplies |
| Availability | Made to order |
Description
Overview
The TDK-Lambda Z20-30-L-U is a 20V/30A DC power supply featuring front-panel binding post output jacks for convenient direct connections to test equipment and components. This 600W supply combines ease-of-use with programmable control through USB, RS-232, and RS-485 interfaces, making it ideal for bench-top applications and automated test systems.
Key Features
- 20V/30A output (600W total)
- Front-panel 4mm binding post output jacks for direct connections
- Constant voltage and constant current operation modes
- Built-in USB, RS-232, and RS-485 connectivity
- User-programmable output signal pins
- Bench or rack-mount configuration (2U high)
- Input voltage selectable between 115-230VAC
- 5-year warranty
Applications
- Bench-top testing with direct output connections
- Component validation and prototype development
- Educational laboratories and training facilities
- Field service and equipment commissioning
Specifications
| Voltage Range Selector | 20-29.9 |
| Output Voltage | 20 V |
| Current Range Selector | 30-49.9 |
| Output Current | 30 A |
| Power Range Selector | 500-999 |
| Power Rating | 600 W |
| Mounting Type | Bench Top |
| Input Voltage | 85-265 VAC |
| Series | Z+ Series |
| Display | Digital |
| Interface | USB,RS-232,RS-485 |
| Number of Outputs | Single Output |
| Programmable | Yes |
| Rack Space | 2U |
| Special Features | Front Panel Binding Posts |
