TDK-Lambda Z20-20-L-U DC Power Supply
Request a quote
TDK-Lambda Z20-20-L-U 400W single-output DC power supply with 20V/20A, USB, RS-232, RS-485, and front panel output jacks.
Product details
| Model | Z20-20-L-U |
| Manufacturer | TDK-Lambda |
| Category | Single Output DC Supplies |
| Availability | Made to order |
Description
Overview
The TDK-Lambda Z20-20-L-U is a compact, 400W single-output DC power supply designed for laboratory, manufacturing, and test applications. It provides stable 20V at 20A output with multiple interface options including USB, RS-232, and RS-485 connectivity. The unit features front panel output jacks for direct connection and supports both bench and rack-mount configurations.
Key Features
- Output: 20V, 20A (400W maximum)
- Built-in USB, RS-232, and RS-485 interfaces for remote control and monitoring
- Constant current and constant voltage operating modes
- Front panel 4mm binding post output jacks for direct equipment connection
- Selectable 115V/230V AC input, 85–265VAC operating range
- 2U high, mountable in standard 19-inch racks or for bench operation
- User-programmable output signal pins for integration into automated systems
- 5-year manufacturer warranty
Applications
- Laboratory testing and research equipment power
- Manufacturing and production line power requirements
- Electronic device development and prototyping
- Automated test systems with remote control capabilities
Specifications
| Voltage Range Selector | 20-29.9 |
| Output Voltage | 20 V |
| Current Range Selector | 20-29.9 |
| Output Current | 20 A |
| Power Range Selector | 200-499 |
| Power Rating | 400 W |
| Mounting Type | Bench Top |
| Input Voltage | 85-265 VAC |
| Series | Z+ Series |
| Display | Digital |
| Interface | USB,RS-232,RS-485 |
| Number of Outputs | Single Output |
| Programmable | Yes |
| Rack Space | 2U |
| Special Features | Front Panel Binding Posts |
