TDK-Lambda Z20-10-L-U DC Power Supply
Request a quote
TDK-Lambda Z20-10-L-U is a 20V/10A DC power supply with front panel output jacks, USB, RS-232, RS-485 interfaces for bench or rack installation.
Product details
| Model | Z20-10-L-U |
| Manufacturer | TDK-Lambda |
| Category | Single Output DC Supplies |
| Availability | Made to order |
Description
Overview
The TDK-Lambda Z20-10-L-U is a single output DC power supply rated for 20V at 10A (200W) with front panel binding post output jacks. The front panel output connectors provide convenient manual connection for laboratory and test bench applications.
Key Features
- Output: 20V, 10A, 200W
- Front panel binding post output jacks (4mm connectors)
- Built-in USB, RS-232, and RS-485 interfaces
- Constant current or constant voltage operation modes
- User-programmable output signal pins
- 2U rack height, bench or rack mountable
- Selectable 115–230VAC input with 85–265VAC range
- 5-year warranty
Applications
- Laboratory and test bench power applications
- Manual power distribution in development environments
- Flexible test setups requiring quick output connections
Specifications
| Voltage Range Selector | 20-29.9 |
| Output Voltage | 20 V |
| Current Range Selector | 10-19.9 |
| Output Current | 10 A |
| Power Range Selector | 200-499 |
| Power Rating | 200 W |
| Mounting Type | Bench Top |
| Input Voltage | 85-265 VAC |
| Series | Z+ Series |
| Display | Digital |
| Interface | USB,RS-232,RS-485 |
| Number of Outputs | Single Output |
| Programmable | Yes |
| Rack Space | 2U |
| Special Features | Front Panel Binding Posts |
