TDK-Lambda Z160-4-U DC Power Supply
Request a quote
TDK-Lambda Z160-4-U single output DC power supply, 160V/4A/640W, with USB, RS-232, and RS-485 interfaces, supporting bench or rack mount.
Product details
| Model | Z160-4-U |
| Manufacturer | TDK-Lambda |
| Category | Single Output DC Supplies |
| Availability | Made to order |
Description
Overview
The TDK-Lambda Z160-4-U is a single output DC power supply delivering 160V at 4A (640W) in a compact 2U rack-mount form factor. It supports both bench and rack mounting configurations and offers programmable operation through multiple communication interfaces. The unit is designed for laboratory, test, and industrial applications requiring precise voltage and current regulation.
Key Features
- Constant current or voltage modes with user programmable output signal pins
- Built-in USB, RS-232, and RS-485 interfaces for remote control and monitoring
- Bench or rack mount configuration (2U high)
- Selectable 115–230 VAC input, operates across 85–265 VAC range
- Five-year warranty
Available Options
- IEEE-488.2 (GPIB) interface for automated test equipment
- LAN (Local Area Network) interface for network integration
- IS510 isolated analog voltage programming interface
- IS420 isolated analog current programming interface
- Front panel output binding posts (4 mm diameter)
- Front panel insulated output sockets (4 mm diameter)
Specifications
| Voltage Range Selector | 100-199 |
| Output Voltage | 160 V |
| Current Range Selector | 2.5-4.9 |
| Output Current | 4 A |
| Power Range Selector | 500-999 |
| Power Rating | 640 W |
| Mounting Type | Bench Top |
| Input Voltage | 85-265 VAC |
| Series | Z+ Series |
| Display | Digital |
| Interface | USB,RS-232,RS-485 |
| Number of Outputs | Single Output |
| Programmable | Yes |
| Rack Space | 2U |
| Special Features | Constant Current, Constant Voltage, Master/Slave Modes |
