TDK-Lambda Z100-8-U DC Power Supply

Overview

The TDK-Lambda Z100-8-U is an 800W high-performance switching DC power supply designed for industrial test, measurement, and production applications. Delivering 100V at up to 8A, this unit operates continuously from worldwide AC voltage (85-265VAC) with integrated power factor correction. The 2U form factor (3.5" high) supports both bench and rack mounting configurations for diverse operational environments.

Key Features

• High power density: 800W in 2U form factor
• Wide AC input range: 85-265VAC continuous operation
• Active power factor correction (0.99 typical)
• Built-in USB, RS-232, and RS-485 serial communication interfaces
• Output voltage and current continuously displayed with LED status indicators
• Constant voltage or constant current operating modes
• Front panel adjustable output parameters and protection levels (over-voltage, under-voltage, foldback)
• Parallel operation with active current sharing for up to six identical units
• Five-year warranty; UL Listed and CE Mark certified

Applications

• Industrial test and production systems
• Laboratory equipment and benchtop testing
• High-voltage component testing and validation
• Automated manufacturing systems

Control & Integration

Standard USB and RS-232/RS-485 communication enables PC-based control and system integration. Optional factory-installed LAN, GPIB, and Isolated Analog programming interfaces support advanced automation. Systems with up to 31 units can be networked and controlled together via the communication interfaces.
