TDK-Lambda Z10-40-LAN-U DC Power Supply
Request a quote
TDK-Lambda Z10-40-LAN-U is a 400W DC power supply with 10V/40A output, programmable CV/CC modes, and LAN interface for remote control.
Product details
| Model | Z10-40-LAN-U |
| Manufacturer | TDK-Lambda |
| Category | Single Output DC Supplies |
| Availability | Made to order |
Description
Overview
The TDK-Lambda Z10-40-LAN-U is a 400W single-output DC power supply for automated test systems, laboratory benches, and industrial applications. It delivers 10V at up to 40A with programmable constant voltage and constant current modes, providing precise power control for component testing, equipment verification, and development work.
Key Features
- 10V output at 40A (400W maximum power)
- Programmable constant voltage (CV) and constant current (CC) modes
- LAN interface for remote control and monitoring
- Built-in USB and RS-232/RS-485 serial communication
- Bench or rack mountable (2U height)
- Selectable input voltage (115-230VAC, range 85-265VAC)
- User-programmable output signal pins for custom integration
- 5-year manufacturer warranty
Applications
- Automated test equipment (ATE) and test benches
- Power system development and verification
- Component characterization and burn-in testing
- Industrial process control and power research
- Laboratory bench power for precision experiments
Specifications
| Voltage Range Selector | 1-19.9 |
| Output Voltage | 10 V |
| Current Range Selector | 30-49.9 |
| Output Current | 40 A |
| Power Range Selector | 200-499 |
| Power Rating | 400 W |
| Mounting Type | Bench Top |
| Input Voltage | 85-265 VAC |
| Series | Z+ Series |
| Display | Digital |
| Interface | USB,LAN,RS-232,RS-485 |
| Number of Outputs | Single Output |
| Programmable | Yes |
| Rack Space | 2U |
| Special Features | Constant Current, Constant Voltage, Master/Slave Modes |
