TDK-Lambda Z10-20-L-U DC Power Supply
Request a quote
TDK-Lambda Z10-20-L-U is a 200W programmable DC power supply with 10V/20A output, featuring integrated USB/RS-232/RS-485 and front panel terminals.
Product details
| Model | Z10-20-L-U |
| Manufacturer | TDK-Lambda |
| Category | Single Output DC Supplies |
| Availability | Made to order |
Description
Overview
The TDK-Lambda Z10-20-L-U is a 200W single-output DC power supply designed for laboratory, testing, and industrial applications. This unit delivers 10V at up to 20A with high efficiency and extensive programmable control options, including USB, RS-232, and RS-485 interfaces. The front panel output terminals provide convenient bench-top access.
Key Features
- 200W power output (10V, 20A)
- Wide input voltage range (85-265VAC continuous)
- Power factor correction (0.99 typical)
- Built-in USB, RS-232, and RS-485 interfaces
- Front panel binding post terminals (4mm)
- Optional LAN and GPIB interfaces
- Constant current or constant voltage operating modes
- Programmable protection levels (over-voltage, under-voltage, and foldback)
- Parallel operation capability with active current sharing (up to 6 units)
- Bench or rack mount configuration
- UL listed and CE marked
- 5-year warranty
Applications
- Laboratory testing and equipment development
- Industrial equipment programming and commissioning
- Battery charging and capacity testing
- Burn-in and reliability evaluation testing
Specifications
| Voltage Range Selector | 1-19.9 |
| Output Voltage | 10 V |
| Current Range Selector | 20-29.9 |
| Output Current | 20 A |
| Power Range Selector | 200-499 |
| Power Rating | 200 W |
| Mounting Type | Bench Top |
| Input Voltage | 85-265 VAC |
| Series | Z+ Series |
| Display | Digital |
| Interface | USB,RS-232,RS-485 |
| Number of Outputs | Single Output |
| Programmable | Yes |
| Rack Space | 2U |
| Special Features | Front Panel Binding Posts |
