Sorensen XEL30-3 DC Power Supply
Request a quote
Sorensen XEL30-3 benchtop linear DC power supply delivers 0-30V at 3A (90W) with digital features and small footprint, ideal for laboratory applications.
Product details
| Model | XEL30-3 |
| Manufacturer | Sorensen |
| Category | Single Output DC Supplies |
| Availability | Made to order |
Description
Overview
The Sorensen XEL30-3 is a compact benchtop linear DC power supply designed for laboratory and engineering test applications. It delivers 0-30V at 3A (90W) with precise voltage regulation and supports programmable control via multiple computer interfaces. The unit features a small footprint measuring 4.2 x 11.3 inches, making it ideal for space-constrained laboratory environments.
Key Features
- Linear voltage regulation with 0-30V output at 3A (90W)
- S-Lock function allows setting and locking a fixed output voltage
- V-Span feature enables user-defined minimum and maximum voltage limits for precise knob control
- Output Enable button allows voltage/current setup without powering the output terminals
- Compact benchtop design measuring 4.2 x 11.3 inches (108 x 287 mm)
- Three-year manufacturer warranty
- Interface options: LXI Class C Ethernet, USB, RS-232 (P models); adds GPIB (PG models)
Applications
- Engineering laboratory testing and development
- Automated test equipment (ATE) integration
- Device testing and validation requiring precise voltage control
- System integration with LXI-compliant instruments
Specifications
| Voltage Range Selector | 30-49.9 |
| Output Voltage | 30 V |
| Current Range Selector | 2.5-4.9 |
| Output Current | 3 A |
| Power Range Selector | 1-199 |
| Power Rating | 90 W |
| Mounting Type | Bench Top |
| Input Voltage | 115 VAC |
| Series | XEL Series |
| Display | Digital |
| Interface | None |
| Number of Outputs | Single Output |
| Programmable | No |
| Special Features | Linear, S-Lock, V-Span |
