Siglent SPS5042X Single Output DC Power Supply
Request a quote
Siglent SPS5042X — 40V/60A single-output DC power supply with 720W capacity for lab and industrial testing applications.
Product details
| Model | SPS5042X |
| Manufacturer | Siglent |
| Category | Single Output DC Supplies |
| Availability | Made to order |
Description
Overview
The Siglent SPS5042X is a single-output DC power supply rated for 40V at 60A output with 720W maximum power. It uses switch-mode technology to deliver stable power for electronic testing, equipment development, and industrial applications.
Key Features
- 40V/60A single output with 720W power rating
- Switch-mode design for efficient operation
- Part of the SPS5000X product series
Applications
- Laboratory testing and circuit validation
- Equipment and prototype development
- Industrial power supply applications
Specifications
| Voltage Range Selector | 30-49.9 |
| Output Voltage | 40 V |
| Current Range Selector | 50-99.9 |
| Output Current | 60 A |
| Power Range Selector | 500-999 |
| Power Rating | 720 W |
| Mounting Type | Bench Top |
| Input Voltage | 100-240 VAC |
| Series | SPS5000X Series |
| Display | 2.4 OLED |
| Interface | USB,LAN |
| Number of Outputs | Single Output |
| Programmable | Yes |
| Special Features | Embedded Web Server |
