Preen ADG-L-670-15 is a 10kW programmable DC power supply delivering 670V at 15A with DSP/PWM technology, ideal for PV, EV, and battery simulation applications.
Product details
| Model | ADG-L-670-15 |
| Manufacturer | Preen |
| Category | Single Output DC Supplies |
| Availability | Made to order |
Description
Overview
The Preen ADG-L-670-15 is a 10kW programmable DC power supply featuring high power density, low noise, and tight voltage regulation. Combining DSP and PWM technologies, this supply delivers 670V output at 15A with exceptional stability and measurement accuracy. The ADG-L series is ideal for demanding applications requiring reliable DC power conversion and simulation capabilities.
Key Features
- Output: 670V at 15A, 10kW maximum power
- DSP and PWM technology for high stability and tight regulation
- CV/CC/CP operation modes
- Master/slave parallel operation (up to 135A with 5 units)
- Input voltage: 187–264Vac (1 or 3 phase) or 340–460Vac (3 phase)
- Step and Ramp function for load simulation
- Complete protection: OVP, OCP, OPP, input OVP/UVP, OTP
- Optional solar array simulation with EN50530 formula
- CE and RoHS certified
- Remote control software included
Applications
- Photovoltaic (PV) system testing and simulation
- Electric vehicle (EV) battery charge testing
- Battery charger simulation
- Fuse and contactor load testing
- Solar array simulation and I-V curve analysis
Specifications
| Voltage Range Selector | 500-999 |
| Output Voltage | 670 V |
| Current Range Selector | 10-19.9 |
| Output Current | 15 A |
| Power Range Selector | 10,000-19,999 |
| Power Rating | 10 kW |
| Mounting Type | Bench Top |
| Input Voltage | 187-264/340-460 VAC |
| Series | ADG-L Series |
| Display | 5 Touch Screen |
| Interface | RS-232,RS-485,Analog |
| Number of Outputs | Single Output |
| Programmable | Yes |
| Rack Space | 3U |
| Special Features | Master/Slave Modes, Remote Sense |
