Magna Power TSD10-2000/480+LXI DC Power Supply

Overview

Magna-Power's TSD10-2000/480+LXI is a 20kW programmable DC power supply from the TS Series, optimized for low-voltage, high-current applications. This 4U rack-mount unit with 480V AC input delivers up to 2000A at 10V and includes integrated LXI Ethernet communications for seamless integration into modern test and measurement systems. With full SCPI support and remote control, it is ideal for manufacturing, laboratory, and multi-instrument configurations requiring networked power management.

Key Features

• 20kW output power: 10VDC, 2000ADC
• LXI TCP/IP Ethernet Communications for network integration
• SCPI remote programming API with full command set
• High accuracy voltage and current measurements
• Master-slave functionality for parallel operation and load sharing
• Remote sensing and isolated 37-pin external I/O
• RS232 interface, with Ethernet and optional GPIB connectivity
• 0-10V analog control inputs for external programming
• Programmable protection limits and fast transient response
• Remote interface software with NI LabVIEW and IVI driver support
• Designed and manufactured in the USA

Applications

• Networked test systems and automated test environments
• Laboratory and industrial testing with remote control
• Multi-unit master-slave configurations
• High-current component and device testing
